Example plugin

This page builds a small plugin from scratch - Bookmarks, which lets you bookmark story parts - and then walks through three bundled plugins: Chapter Marker, the smallest one that changes the UI, Author's Note, which changes the prompt sent to the model, and Chinese localization, which adds a language and no code besides the texts. Together they use everything from the previous pages: a bundle, decorators reading arguments, locals and fields, data in attributes, generation listeners, and cleanup on unload.

Bookmarks

What it does:

every story part's menu gets a Toggle bookmark item,
bookmarked parts are marked with ★ in the story sidebar,
the bookmark is stored on the part, so it's kept in backups and copied by Branch Story.

The Bookmarks example: a bookmarked part in the sidebar and the Toggle bookmark menu item

1. Install the application

The plugin compiles against the application's classes, installed in the local Maven repository:

mvn -N install                  # in the repository root: the parent POM the application's POM refers to
cd marginalia
mvn install -DskipTests

2. Create the project

bookmarks/
├── pom.xml
└── src/main/java/com/example/marginalia/bookmarks/
    ├── BookmarksActivator.java
    └── BookmarksExtension.java

Copy marginalia/plugins/chaptermarker/pom.xml and change:

groupId to com.example.marginalia, artifactId to bookmarks, and replace the <parent> (the plugin is outside the repository) with a <version> of its own, e.g. 1.0.1; the dependency on marginalia then needs the version of the installed application instead of ${project.version},
Bundle-Activator to com.example.marginalia.bookmarks.BookmarksActivator,
Import-Package to !com.example.marginalia.bookmarks.* and Export-Package to com.example.marginalia.bookmarks.*.

Keep the rest - the provided dependencies, the AspectJ plugin (for @Configurable) and the bundle plugin. See Plugin basics → pom.xml for what each part does.

3. The activator

It only registers the extension:

package com.example.marginalia.bookmarks;

import com.github.enerccio.marginalia.extensions.MarginaliaExtension;
import org.osgi.framework.BundleActivator;
import org.osgi.framework.BundleContext;
import org.osgi.framework.ServiceRegistration;

public class BookmarksActivator implements BundleActivator {

    private ServiceRegistration<MarginaliaExtension> registration;

    @Override
    public void start(BundleContext context) {
        registration = context.registerService(MarginaliaExtension.class, new BookmarksExtension(), null);
    }

    @Override
    public void stop(BundleContext context) {
        if (registration != null) {
            registration.unregister();
            registration = null;
        }
    }
}

4. The extension

package com.example.marginalia.bookmarks;

import com.github.enerccio.marginalia.domain.model.impl.ChatMessage;
import com.github.enerccio.marginalia.domain.service.ChatMessageService;
import com.github.enerccio.marginalia.domain.service.ExtensionService;
import com.github.enerccio.marginalia.domain.service.ExtensionService.ExtendableMethodContext;
import com.github.enerccio.marginalia.domain.service.ExtensionService.ExtensionDecorator;
import com.github.enerccio.marginalia.domain.service.OsgiService;
import com.github.enerccio.marginalia.extensions.MarginaliaExtension;
import com.github.enerccio.marginalia.ui.dialogs.manuscript.ManuscriptStoryPart;
import com.google.gson.JsonObject;
import com.vaadin.flow.component.ComponentUtil;
import com.vaadin.flow.component.button.Button;
import com.vaadin.flow.component.contextmenu.ContextMenu;
import com.vaadin.flow.component.contextmenu.MenuItem;
import com.vaadin.flow.component.notification.Notification;
import org.osgi.framework.Bundle;
import org.slf4j.Logger;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.beans.factory.annotation.Configurable;

import java.util.Collections;
import java.util.List;
import java.util.Set;
import java.util.WeakHashMap;

@Configurable
public class BookmarksExtension implements MarginaliaExtension {
    /** The logger of the extension, its lines go to Admin → Extensions → Log. */
    private Logger log;

    private static final String KEY = "com.example.marginalia.bookmarks";
    private static final String MENU_ITEM_KEY = KEY + ".menuItem";

    private static final String STORY_PART = "com.github.enerccio.marginalia.ui.dialogs.manuscript.ManuscriptStoryPart";
    private static final String MESSAGE_CARD = STORY_PART + "$ChatMessageCard";

    @Autowired
    private ChatMessageService chatMessageService;

    private final Set<ContextMenu> menus = Collections.synchronizedSet(Collections.newSetFromMap(new WeakHashMap<>()));
    private List<ExtensionDecorator> decorators = List.of();

    @Override
    public void onExtensionLoad(Bundle bundle, OsgiService osgiService, ExtensionService extensionService) {
        log = osgiService.createLogger(bundle);
        ExtensionDecorator menuDecorator = new ExtensionDecorator() {
            @Override
            public void onMethodEnter(Object instrumented, ExtendableMethodContext context) {
            }

            @Override
            public void onMethodLeave(Object card, ExtendableMethodContext context, Throwable throwing) {
                if (throwing != null) {
                    return;
                }
                ContextMenu menu = context.getReflectiveFieldValue(card, "hamburgerMenu", ContextMenu.class);
                if (menu == null || ComponentUtil.getData(menu, MENU_ITEM_KEY) != null) {
                    return;
                }
                MenuItem item = menu.addItem("Toggle bookmark", event -> {
                    try {
                        // read the field when clicked - the card replaces its message on every save
                        ChatMessage shown = context.getReflectiveFieldValue(card, "message", ChatMessage.class);
                        ChatMessage fresh = chatMessageService.find(shown.getId());
                        setBookmarked(fresh, !isBookmarked(fresh));
                        chatMessageService.save(fresh);

                        // redraw the story so the sidebar shows the change
                        ManuscriptStoryPart storyPart = context.getReflectiveFieldValue(card, "this$0", ManuscriptStoryPart.class);
                        context.callReflectiveMethod(storyPart, "renderStoryContent", new Class<?>[0], new Object[0], void.class);
                    } catch (Exception e) {
                        log.error("Cannot toggle bookmark", e);
                        Notification.show("Cannot toggle bookmark: " + e.getMessage());
                    }
                });
                ComponentUtil.setData(menu, MENU_ITEM_KEY, item);
                menus.add(menu);
            }
        };

        ExtensionDecorator sidebarDecorator = new ExtensionDecorator() {
            @Override
            public void onMethodEnter(Object instrumented, ExtendableMethodContext context) {
            }

            @Override
            public void onMethodLeave(Object storyPart, ExtendableMethodContext context, Throwable throwing) throws Exception {
                if (throwing != null) {
                    return;
                }
                ChatMessage msg = context.getMethodArgument("msg", ChatMessage.class);
                if (isBookmarked(msg) && context.hasLocalVariable("sidebarBtn", Button.class)) {
                    Button sidebarBtn = context.getLocalVariable("sidebarBtn", Button.class);
                    sidebarBtn.setText("★ " + sidebarBtn.getText());
                }
            }
        };

        try {
            extensionService.registerDecorator(menuDecorator, MESSAGE_CARD, "createMenuItems");
            extensionService.registerDecorator(sidebarDecorator, STORY_PART, "createSidebarButton");
            decorators = List.of(menuDecorator, sidebarDecorator);
        } catch (Exception e) {
            // logged by Marginalia, which then unloads the extension again
            throw new IllegalStateException("Bookmarks extension failed to load", e);
        }
    }

    @Override
    public void onExtensionUnload(Bundle bundle, OsgiService osgiService, ExtensionService extensionService) {
        decorators.forEach(extensionService::unregisterDecorator);
        decorators = List.of();

        synchronized (menus) {
            for (ContextMenu menu : menus) {
                // menus belong to other sessions - change them under their own lock
                menu.getUI().ifPresent(ui -> ui.access(() -> {
                    MenuItem item = (MenuItem) ComponentUtil.getData(menu, MENU_ITEM_KEY);
                    if (item != null) {
                        menu.remove(item);
                        ComponentUtil.setData(menu, MENU_ITEM_KEY, null);
                    }
                }));
            }
            menus.clear();
        }
    }

    static boolean isBookmarked(ChatMessage message) {
        JsonObject attributes = message != null ? message.getAttributes() : null;
        return attributes != null && attributes.has(KEY) && attributes.get(KEY).getAsBoolean();
    }

    static void setBookmarked(ChatMessage message, boolean bookmarked) {
        if (message.getAttributes() == null) {
            message.setAttributes(new JsonObject());
        }
        if (bookmarked) {
            message.getAttributes().addProperty(KEY, true);
        } else {
            message.getAttributes().remove(KEY);
        }
    }
}

This example decorates createMenuItems to show the technique; for a menu item of the story editor prefer the StoryMenuRegistry (see UI extensions), which also gives the item a keyboard shortcut and needs no cleanup.

How it works:

Two decorators. menuDecorator runs after ChatMessageCard.createMenuItems() - the card runs it when its menu is opened for the first time (not when the card is created, so the cards of a long story stay cheap), so every menu that is opened gets the item. sidebarDecorator runs after ManuscriptStoryPart.createSidebarButton(msg, orderId, dbId), which renderStoryContent() calls for each part of the branch.
Reaching the components. The menu is the card's field hamburgerMenu; the sidebar button is the local variable sidebarBtn of createSidebarButton, the part is its argument msg. Both names are checked before use (hasLocalVariable) or fail with a logged warning if the application changes.
Adding once. ComponentUtil.setData(menu, MENU_ITEM_KEY, item) marks the menu; a second call for the same menu does nothing.
Data. The bookmark is one boolean under the plugin's key in the part's attributes. The click listener reads the card's message field at click time and reloads the part (chatMessageService.find(id)) before changing it, because the card's copy may be stale (Extended attributes).
Redrawing. After saving it calls the story part's private renderStoryContent() through callReflectiveMethod, reaching the outer ManuscriptStoryPart through the inner class's this$0 field. The redraw runs createSidebarButton again, so the sidebar decorator adds the ★.
Unloading. Decorators are unregistered; menu items are removed from the tracked menus inside each menu's own ui.access(...), because they belong to other users' sessions (Extending the UI → Unloading). Sidebar buttons lose their ★ on the next redraw.
Errors. onExtensionLoad runs without a UI, so it throws instead of opening an error dialog; Marginalia logs the error and unloads the extension again.

With Chapter Marker installed too, both plugins decorate createSidebarButton, and decorators run in the order the plugins were loaded. Bookmarks prefixes the text, so it works after Chapter Marker; Chapter Marker replaces the text of chapter parts, so the ★ of a bookmarked chapter is lost when Chapter Marker runs second (and when the part is edited).

5. Build and load

cd bookmarks
mvn package                     # target/bookmarks-1.5.0.jar

Load target/bookmarks-1.5.0.jar in Admin → Extensions and open a book (books that were already open need to be closed and opened again). Open a part's menu, choose Toggle bookmark - the part's sidebar entry gets the ★.

If nothing appears, look in the log for Mod 'com.example.marginalia.bookmarks.BookmarksExtension$...' skipped on ... (a name that doesn't exist) or Unhandled exception in extension .... The lines of the extension itself (here log.error("Cannot toggle bookmark", e)) are in Admin → Extensions → Log of the extension, see Logging.

Where to go from here

Show the bookmarks in a tab of their own: decorate renderStoryContent() and add a tab to leftBar, like Side Query (A tab next to the story).
Put bookmarked parts into the prompt: register a generation listener, like Author's Note (Walkthrough: Author's Note, Generation events).

Walkthrough: Chapter Marker

marginalia/plugins/chaptermarker turns the story sidebar into a table of contents: a part whose text contains a Markdown heading is shown as 5. Chapter 3: The Harbour, highlighted. It has two classes and no data of its own - the heading is part of the story text.

ChapterMarkingActivator is the same as the Bookmarks activator. ChapterMarkingExtension registers two decorators in onExtensionLoad.

Labelling the sidebar - after ManuscriptStoryPart.createSidebarButton(msg, orderId, dbId):

ChatMessage msg = context.getMethodArgument("msg", ChatMessage.class);
Integer orderId = context.getMethodArgument("orderId", int.class);      // primitive argument: ask for int.class

VerticalLayout sidebarList = context.getReflectiveFieldValue(instrumented, "sidebarList", VerticalLayout.class);

Button sidebarBtn = null;
if (context.hasLocalVariable("sidebarBtn", Button.class)) {
    sidebarBtn = context.getLocalVariable("sidebarBtn", Button.class);
} else if (sidebarList.getComponentAt(sidebarList.getComponentCount() - 1) instanceof Button lastBtn) {
    sidebarBtn = lastBtn;                                                // fallback if the local is renamed
}

It remembers the button's original text, the order and the part's uuid on the button (ComponentUtil.setData(...)), then sets the chapter title and style if the part has a heading.

Following edits - after ManuscriptStoryPart$ChatMessageCard.autosaveAndSwapToMarkdown(), which saves an edited part:

ChatMessage chatMessage = context.getReflectiveFieldValue(instrumented, "message", ChatMessage.class);
ManuscriptStoryPart parentPart = context.getReflectiveFieldValue(instrumented, "this$0", ManuscriptStoryPart.class);
VerticalLayout sidebarList = context.getReflectiveFieldValue(parentPart, "sidebarList", VerticalLayout.class);

It finds the sidebar button whose stored uuid matches the edited part and relabels it - or restores the original text when the heading was removed. The data stored on the button in the first decorator is what makes this possible without rebuilding the sidebar.

Unloading unregisters both decorators. Labels already changed stay until the story is redrawn, which is acceptable here: they're just text.

What to take from it:

arguments, locals and fields are all used, each with the right accessor;
primitive arguments are read with the primitive type;
a fallback for the local variable keeps the plugin working if the variable is renamed;
component data (ComponentUtil) carries state from one hook to another.

The other bundled plugins build on the same pieces: Reviewer and Side Query add menu items, tabs, settings panels and call the model (Extending the UI); Lorebook VCS stores larger data in a lorebook's attributes (Extended attributes); Lore Generator adds a button to every row of the lorebook grid and streams a generation from the model into a dialog; Author's Note, below, changes the prompt of every generation.

Walkthrough: Author's Note

marginalia/plugins/authorsnote sends a per-book note to the model with every generation: an Author's Note tab next to the story outline edits it, a generation listener inserts it into the prompt. It shows the one thing decorators can't do - change what the model gets.

Class	Does
`AuthorsNoteData`	The note: on/off, the text, a private scratchpad, the insertion depth and the role. Stored in the book's attributes under the package name.
`AuthorsNoteService`	Loads and saves the data, counts the note's tokens, inserts the note into a payload.
`AuthorsNoteView`	The sidebar tab with a token estimate of the note; every change is saved right away.
`AuthorsNoteExtension`	Adds the tab on leave of `ManuscriptStoryPart.renderStoryContent()` (like Side Query) and registers the listener.

Hooking into generation - onExtensionLoad registers two listeners next to the decorator and keeps the registrations:

reserveRegistration = storyGenerationService.addEventListener(Events.BEFORE_PREPARE_CONTENT,
        this::reserveAuthorsNote);
payloadRegistration = storyGenerationService.addEventListener(Events.AFTER_PREPARE_PAYLOAD,
        this::insertAuthorsNote);

BEFORE_PREPARE_CONTENT comes before the generation decides how much of the story fits into the context. The listener loads the note, keeps it in the generation's properties and reserves its tokens, so the story gets less room:

AuthorsNoteData data = authorsNoteService.loadCurrent(manuscript);
event.getProperties().put(AuthorsNoteData.KEY, data);
long tokens = authorsNoteService.countTokens(manuscript, data);
event.getPrePromptData().setReservedTokens(event.getPrePromptData().getReservedTokens() + tokens);

AFTER_PREPARE_PAYLOAD comes when the list of chat messages for the model is complete; what the listener sets is what is sent:

private void insertAuthorsNote(GenerationControllerEvent event, EventChain chain) {
    try {
        AuthorsNoteData data = event.getProperty(AuthorsNoteData.KEY);   // the note that was counted
        if (data != null) {
            event.setPayload(authorsNoteService.insertNote(event.getPayload(), data));
        }
    } catch (Exception e) {
        log.warn("Failed to insert the author's note: {}", e.getMessage(), e);
    } finally {
        chain.next();
    }
}

Unloading unregisters both listeners besides removing the decorator and the tabs - a listener left registered would keep changing the prompts of every user.

What to take from it:

chain.next() in finally - the generation waits for every listener;
listeners are global, so act only on the data of the book being generated;
reserve the tokens of what you add (PrePromptData.reservedTokens) before the budget is computed, and add to the reservation instead of overwriting it;
pass state from one event to the next in event.getProperties(), under your package name;
build a new payload and setPayload(...) it instead of changing the list you got.

Generation events explains the payload, the choice of the events and reserving tokens in detail.

Walkthrough: Chinese localization

marginalia/plugins/chineselocalization adds Simplified Chinese to the language selector of the workspace. It is the smallest possible plugin - no decorators, no UI, no data - and shows the third optional interface of an extension besides ExtensionHasCss: ExtensionHasLocalization.

chineselocalization/
├── pom.xml
└── src/main/java/com/github/enerccio/marginalia/extensions/chineselocalization/
    ├── ChineseLocalizationActivator.java   registers the extension service
    ├── ChineseLocalizationExtension.java   returns the bundle
    └── LocalizationBundleZH.java           the texts

The pom.xml is the one of the other plugins without what the plugin doesn't use: it needs only the application (classes classifier) and the Felix framework, both provided, and the bundle plugin - no AspectJ, since there is no @Configurable class, and no Vaadin.

The extension implements MarginaliaExtension as always - both methods stay empty, there is nothing to set up - and ExtensionHasLocalization:

public class ChineseLocalizationExtension implements MarginaliaExtension, ExtensionHasLocalization {

    @Override
    public void onExtensionLoad(Bundle bundle, OsgiService parentService, ExtensionService extensionService) {
    }

    @Override
    public void onExtensionUnload(Bundle bundle, OsgiService parentService, ExtensionService extensionService) {
    }

    @Override
    public List<LocalizationBundle> getLocalizationBundles() {
        return List.of(new LocalizationBundleZH());
    }
}

Marginalia calls getLocalizationBundles() right after onExtensionLoad and registers the bundles in Localization; when the extension is unloaded they are removed again. Nothing else is needed: the language shows up in the LanguageSelector of every workspace the next time it is attached, and a user who picks it is shown the whole UI in it after the page reloads.

The bundle extends LocalizationBundleBase: loadMessages() fills the texts with setValue, the other methods describe the language.

public class LocalizationBundleZH extends LocalizationBundleBase {

    @Override
    public Language getLanguage() {
        return Language.of("zh");               // the code saved in the user's settings
    }

    @Override
    public String getDisplayName() {
        return "中文（简体）";                      // shown in the selector, in the language itself
    }

    @Override
    protected void loadMessages() {
        setValue(L.LABEL_YES, "是");
        setValue(L.LABEL_NO, "否");
        // ... one setValue for every key of L
    }

    @Override
    public Locale getLocale() {
        return Locale.SIMPLIFIED_CHINESE;       // collation of lists, natural order of names
    }

    @Override
    public DateFormat getDateFormat() {
        return new SimpleDateFormat("yyyy-MM-dd");
    }
    // getHourFormat() and getDateHourFormat() the same way
}

What to take from it:

a language code is the identity of a bundle: only one bundle per code exists. A second one is refused (and logged) - an extension can add languages but not replace the English texts or the Japanese ones of the application;
a bundle doesn't have to be complete: a key it lacks is shown in the default language, and the application logs a warning listing the missing keys when the bundle is registered. A plugin built for an older version keeps working when the application adds keys;
the placeholders (%s, %d) of a text must match the English text in number and order of their types, the application formats the text with them. Copy LocalizationBundleEN as the start and translate in place;
the bundle is created in getLocalizationBundles(), and the texts are looked up when needed, so a plugin's own user interface that uses Localization gets the right language without more work;
unloading the plugin makes sessions that used its language fall back to the default one - nothing is lost, the user's setting stays and works again when the plugin is loaded.

To try it, build and load it like any plugin (Build and load): in Admin → Extensions load chineselocalization-1.5.0.jar, then pick 中文（简体） in the language selector.
